simpleRTK3B Pro

simpleRTK3B Pro is a standalone board that allows to evaluate triple band millimeter RTK GNSS positioning technology including microSD datalogging and with an accessory native Ethernet functionality. It’s based on Septentrio mosaic-X5 module and can be used standalone. Or connected with Arduino, Ardupilot / Pixhawk (JST connector), Raspberry Pi, Nvidia Jetson and STM32 Nucleo platforms, as a shield. It can provide up to 100 RTK positions every second.

This board is ideal for advanced projects that require high update rate, best in class accuracy or CORS base station installations.
More details available in the Specification and Documentation tabs.

Good to know:
– This product includes a microSD card native datalogger (microSD card not included)
– This product is compatible but doesn’t include a multiband GNSS antenna, which is necessary to use the product.
– The module will not give good performance with a standard GNSS antenna, requires a multiband one. Best performance is achieved with a triple band antenna.
– This product is compatible but doesn’t include radio, which is necessary to connect to another base.
– This board is recommended if you want to test Septentrio mosaic-X5 performance.
– The onboard XBee socket can be used to expand functionality with Plugin accessories (MR/LR/XLR radios, Bluetooth, WiFi, RS232, Canbus, L-Band, 4G/3G/2G).
– You can use the Shield for Second Plugin socket to connect 2 plugins at the same time.
– This product already includes a native microSD datalogger (microSD card not included).
– This product already has embedded Ethernet functionality (special Ethernet adapter not included, see related product below).
– Compatible with Ardusimple plastic case
– Ardupilot compatible via JST-GH standard connector
– Timepulse output and Event input
– This product is a low cost alternative to Trimble BD970
